ATV71HU75N4 TELEMECANIQUA ATV71 AC DRIVE - 7.5kW-10HP
| Component name | ATV71 |
|---|---|
| Motor power kW | 7.5 kW, 3 phases at 380...480 V |
| Motor power hp | 10 hp, 3 phases at 380...480 V |
| Maximum motor cable length | 50 m shielded cable 100 m unshielded cable |
| power supply voltage | 380...480 V - 15...10 % |
| Network number of phases | 3 phases |
| Line current | 22.2 A for 480 V 3 phases 7.5 kW / 10 hp 27 A for 380 V 3 phases 7.5 kW / 10 hp |
| EMC filter | Integrated |
| Assembly style | With heat sink |
| Apparent power | 17.8 kVA at 380 V 3 phases 7.5 kW / 10 hp |
